FabricAir® Poly


Sales Catalog, Poly pages (pdf 0.7 mb)

OriFlow™
Air exits at high
velocity from the large
perforations. .
ZIPPERS
Heavy-duty industrial zippers; neatly folded under an extra seam
separate individual duct lengths
TAG NUMBERS
Individual duct lengths are fitted
with unique tag numbers, making
installation and tracking of duct
systems easy
SAFE MOUNTING
Fabric duct connect onto
sheet metal systems secured
with a pinch-down duct belt.



WARRANTY
1-year warranty.
- only in the US and Canada.
PRICE INDEX [A-L]
Indication of
price level compared
to our other fabrics.
A: Most expensive.
L: Least expensive.

FabricAir® Poly is an extremely cost-effec tive alternative to other forms of air distribution systems. Used mainly in tough
industrial applications this rugged duct performs well in supplying fresh and heated air to personnel working in polluted spaces. FabricAir® Poly is often used as a temporary means of ventilation. Selecting the Sonic- Flow™ option results in low air velocity
exiting the micro holes. A medium velocity is achieved by selecting the PerfoFlow™ option while long penetrating throws are
available by using the OriFlow™ option.




FLOW MODELS AVAILABLE
Find guide to select flow
model here.





OriFlow


DUCT PROFILES
AVAILABLE

Round

STANDARD COLORS
AVAILABLE

ACCESSORY
COLORS
Accessory colors
used when
combined with a
standard fabric
color

 Nozzles  (NozzFlow™)
 Sliders
 Hooks
 Mesh
 (MeshFlow™)




The colours shown here are only intended as a guide.
Please contact FabricAir® for exact colour samples.
